Compact active loudspeaker system
- Flexible use
- Integrated 3-channel digital power amplifier with 1000 W output power
- Can be used as a classic stereo system with one subwoofer and two satellites, or as a powerful mono system by means of the mechanical connection of the two satellites
- Can also be used as a powerful stereo system with two coupled ES503 systems
- Matching protective cover for the subwoofer: Art. 373941, matching protective cover for the top: Art. 373942 (both not included)
- Colour: White
ES503 Sub:
- Driver: 12″ woofer with 2″ diaphragm compression driver
- Extensive input section with high-resolution OLED display for easy operation
- Integrated 3-channel mixer and Bluetooth receiver for audio streaming
- Digipro G3 digital subwoofer with 1000 W/PRG
- OLED display plus rotary-push encoder
- 3 mic line inputs with XLR/jack combo socket
- Bluetooth® stereo receiver for audio streaming
- Presets for stereo, mono and dual-mono setup
- 4-channel digital mixing section
- Mini-USB port for service and updates
- XLR output for mix or aux output
- 2 Speaker Twist connections for mid-high tops
- Bass-reflex design
- 15 mm multiplex wood cabinet
- Two handles
- M20 thread
- Dimensions: 465 x 400 x 430 mm
- Weight 16.4 kg
ES503 TOP A/B:
- Equipment: 4 x 3″ neodymium full-range loudspeakers
- Phase plugs and mechanical arrangement optimise acoustic properties
- Plastic cabinet incl. 25 mm stand mount
- Electrical and mechanical connections for coupling two ES503 tops
Included:
- 1x ES503 Top-A
- 1x ES503 Top-B
- 1x ES503 sub
- 1x divisible distance rod 25 mm
- 1x speaker twist cable 2 m
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceDecember 2021
- Item number527567
- Sales Unit1 piece(s)
- more than 150 people Yes
- more than 300 people No
- Incl. Mixer No
- Incl. Subwoofer Yes
- Active Speaker Yes
- Line Array / Column Yes
- Width465 mm
- Depth430 mm
- Satellite Speaker SystemYes
- Weight18,3 kg
- Sub Woofer1×12
- Speakers (Row)8×3
- Midrange Driver4x 3″
- Woofer size1x 12″
- Power (Manufacturer Info)1000 W
- Inputs simultaneously3
- Mic Preamp1
- Line OutXLR
- Bluetooth PlayYes
- ColourWhite
- Cover373941, 373942
