Active 3-Way Monitor
- Closed housing
- Equipped with: 2x 8″ woofer, 1x 5″ midrange driver and 1x AMT tweeter (1.1″ x 1.7″)
- Amplifier power RMS: 2x 225 W (woofer – Class D) + 150 W (midrange – Class D) + 75 W (tweeter – Class D)
- Frequency range: 28 – 20,000 Hz (+/-4.6 dB), 80-20,000 Hz (+/-2.0 dB)
- Integrated AD converter with 24 bit / 192 kHz
- Crossover frequency at 115 Hz and 2800 Hz
- Cubemix mode can be activated via the supplied footswitch
- Rotatable baffle for midrange and tweeter (tweeter optionally at the top or bottom)
- Sonarworks integration – SoundID reference profiles can be saved and loaded directly onto the speaker’s DSP
- DCT (DSP Configuration Tool) software for managing room correction profiles
- Dimensions (D x W x H): 351 x 241 x 363 mm
- Weight: 12.6 kg
Connections:
- 1 x XLR audio input
- 1 x TRS jack input
- 1 x XLR AES/EBU input
- SPDIF input/output
- USB 2.0 type B (DSP settings)
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceAugust 2025
- Item number622441
- Sales Unit1 piece(s)
- Woofer Size Class 8″
- Number of Ways 3
- Speaker Housing – Woofer System Closed
- Coaxial System No
- Power per Unit 675 W
- Frequency range 28 Hz – 20000 Hz
- Analogue XLR Input Yes
- Analogue Input(Jack) Yes
- Analogue Input (Mini Jack) No
- Analogue Input (RCA) No
- Digital input Yes
- Manual Sound Adjustment Yes
- DSP Room Correction optional with Sonarworks SoundID
- Construction Typ – Bass SystemClosed
- Power per Piece675 W
- Frequency Range from28 Hz
- Frequency Range to20000 Hz
- Weight12,6 kg
- Analog XLR InputYes
- Analog TRS InputYes
- Digital InputYes
- Manual EQYes
- Woofer2x 8″
- Midrange Speaker5″
- Mid-Range Driver5″
- TweeterAMT
- Height351 mm
- Width241 mm
- Depth363 mm
