USB 2.0 Audio Interface
- 24-bit / 192 kHz
- Ten inputs and four outputs
- Two Clarett microphone preamps with Air mode model the classic ISA110 micpreamp sound
- +48 V phantom power switchable
- USB-C bus power operation (15 watts USB-C port required)
- Two mic / instrument / line inputs: XLR / jack 6.3 mm combo
- Four line outputs: 6.3 mm jack
- MIDI in / out
- Combined ADAT / S/PDIF input optical
- Stereo headphone output: 6.3 mm jack
- USB-C connector
- Desktop housing
- Dimensions (W x H x D): 210 x 55 x 161 mm
- Weight: 1.11 kg
- Including USB cable (standard USB and USB Type-C) and Hitmaker Expansion Software Bundle (Ableton Live Lite, Pro Tools Intro+ and Avid Complete Plugin Bundle)
Hitmaker Expansion Plugins:
- LANDR – AI-based mastering tool (two-month subscription)
- Softube Flow Guitar Essentials
- XLN Audio Addictive Keys Studio Grand Piano – Virtual Keyboard Instruments
- XLN Audio Addictive Drums 2: Studio Rock – Virtual Drum Library
- Celemony Melodyne Essential
- Brainworx Bx_console Focusrite SC – Channelstrip
- Focusrite Red 2 & 3 Plug-in Suite – EQ and Compressor
- Relab’s LX480 Essentials – Reverb
- Native Instruments MASSIVE, FAST Balancer
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceDecember 2021
- Item number524285
- Sales Unit1 piece(s)
- Recording / Playback Channels 10×4
- Number of Mic Inputs 2
- Number of Line Inputs 2
- Instrument Inputs 2
- Number of Line Outs 4
- Headphone Outs 1
- Phantom Power Yes
- Number of S/PDIF Connectors 1
- Number of ADAT Connectors 1
- Numer of AES/EBU Connectors 0
- Number of MADI Connectors 0
- Ethernet 0
- Other Connectors None
- MIDI interface Yes
- Word Clock No
- Max. Sampling Rate in kHz 192 kHz
- Max. Resolution Rate in Bits 24 bit
- USB Bus-Powered Yes
- Incl. power supply Yes
- USB Version 2.0
- Width 210 mm
- Depth 161 mm
- Height 55 mm
- Connection Format USB port Type C
- Included in deliveryPower Supply, USB-C Cable, USB-A to USB-C Cable
- Zero latency monitoringYes
