USB 3.0 Audio Interface
- Routing via TotalMix FX or TotalMix Remote allows remote control via iOS, PC or Mac
- Can be used standalone as 64-channel Dante / MADI converter
- Sampling rate: 192 kHz
- 128 Input and 128 output channels
- 128 Ravenna channels I/O
- 64 Channels MADI I/O
Connections
- USB 3.0
- 4 Ethernet ports
- Coaxial MADI I/O
- Headphone TRS stereo output
- Word clock I/O
Note: no external power supply required
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceFebruary 2023
- Item number553561
- Sales Unit1 piece(s)
- Recording / Playback Channels 128×128
- Number of Mic Inputs 0
- Number of Line Inputs 0
- Instrument Inputs 0
- Number of Line Outs 0
- Headphone Outs 1
- Phantom Power No
- Number of S/PDIF Connectors 0
- Number of ADAT Connectors 0
- Numer of AES/EBU Connectors 0
- Number of MADI Connectors 1
- Ethernet 4
- Other Connectors None
- MIDI interface No
- Word Clock 1xIn, 1xOut
- Max. Sampling Rate in kHz 192 kHz
- Max. Resolution Rate in Bits 24 bit
- USB Bus-Powered Yes
- Incl. power supply No
- USB Version 3.0
- Width 128 mm
- Depth 55 mm
- Height 22 mm
- Connection Format USB port Type B
- Included in deliveryPower Supply, Power Cable, USB-3.0-A to USB-3.0-B Cable
- Zero latency monitoringYes
