Passive 15″ Coaxial Multi-Functional Speaker
- Power rating: 800 W RMS / 1600 W peak
- Equipped with: One 15″ coaxial chassis, one 1.4″ compression driver with 3″ diaphragm
- Max. sound pressure level (SPL): 133 dB
- Frequency range: 55 Hz – 17,000 Hz
- Dispersion angle (H x V): 70° x 55º
- Impedance 8 ohm
- Connectors: Three SpeakON NL4MP
- Housing material: Multiplex birch wood
- Slanted monitor angle
- 35 mm stand flange mount
- Two Air-Cargo rigging rails
- Dimensions (W x H x D): 605 x 348 x 500 mm
- Weight: 23.8 kg
- Colour: Black
Note: Operation recommended with dedicated TW AUDiO presets on LAB groups, Powersoft or Dynacord TGX, IPX and L-Series amplifiers
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceMarch 2025
- Item number607087
- Sales Unit1 piece(s)
- Manufacturers Information Power Handling 1600 W
- Impedance 8 Ohms
- Number of Woofers 1
- Woofers in Inch 15″
- Colour Black
- Width 605 mm
- Depth in mm 500 mm
- Height 348 mm
- Weight in kg 23,8 kg
- Monitor Angle Yes
- IP Class None
- RMS Power800 W
- Impedance in Ohms8 Ohms
- FlyableFlying Bracket
- SPL in dB133 dB
- Maximal SPL133 dB
- Number of Midrange Speakers0
- Number of Mid-Tone Speakers0
- Mid-Tone Speakers in Inchnone
- Midrange Speaker in Inch0″
- Number of HT-Speaker1
- Number of HT-Speakers1
- HT-Speakers in Inch1,4″
- Stand Flange35 mm
- Number of Ways2-Way
- Housing MaterialWood
- ConstructionMonitor
- InputSpeaker-Twist
- OutputSpeaker-Twist
- Horizontal Beam Angle70 °
- Frequency Range (-10dB) from55 Hz
- Frequency Range (-10dB) to17000 Hz
- Vertical Beam Angle55 °
